Priora Pencil Edge Permeable Paving
Tried and tested, this new Priora variant has been developed to minimise vibration and surface noise from the wheeled traffic that uses it, making it an ideal paving product for car parks and cycleways.
The chamfer on the edge of the block has been reduced to provide a smooth, flat surface and it comes in a robust 80mm thickness. The paver comes in a pack size of 6.16m² and also benefits from our patented Priora nib, which means excellent hydraulic and structural performance.
Expect longevity and low maintenance requirements with this Priora Permeable Paving, as well as a contemporary finish with its range of colours, including Buff, Charcoal and Brindle.
- Plan size: 200x100mm
- Hydraulic benefits
- Suitable for both residential and wheeled traffic environments
- 4 colour options
Price Range
- £
- £
- £
Maximum Loading Classification i✕This is the maximum loading for the product.
However this is subject to using the appropriate installation method, bond pattern and the sub-base design.
For tailored support with a pavement design, please contact us:
grouptechnicalservices@marshalls.co.uk
However this is subject to using the appropriate installation method, bond pattern and the sub-base design.
For tailored support with a pavement design, please contact us:
grouptechnicalservices@marshalls.co.uk
Category 7 - 100 large goods vehicles per week
NBSPlus Codes
Q24 110
Q24 112
Q24 10
Q24 113
Carbon Footprint
From 20 kg CO2 per m²
Technical Downloads (5)
- dop Download dop Add to Project dop
- Priora Pencil Edge 200 x 100 x 80 Datasheet Download Priora Pencil Edge 200 x 100 x 80 Datasheet Add to Project Priora Pencil Edge 200 x 100 x 80 Datasheet
Certification Logos and Accreditations
Datasheets
Add All to Project- Priora Pencil Edge 200 x 100 x 80 Datasheet Download Priora Pencil Edge 200 x 100 x 80 Datasheet Add to Project Priora Pencil Edge 200 x 100 x 80 Datasheet
NBSPlus
Add All to Project- Block Paving Pencil Edge Priora Download Block Paving Pencil Edge Priora Add to Project Block Paving Pencil Edge Priora
CE Mark
Add All to ProjectTechnical Documents
Add All to Project- marshalls permeable paving design guide Download marshalls permeable paving design guide Add to Project marshalls permeable paving design guide
- how to maintain a priora permeable pavement Download how to maintain a priora permeable pavement Add to Project how to maintain a priora permeable pavement
Product Details - Priora Pencil Edge
| Product Name | id | Plan Size (mm) | Length (mm) | Width (mm) | Depth (mm) | Approx Unit Weight (kg) | Approx Pack Weight (kg) | Pack Size (m²) | Finish | Permeability L/S/H | Made to Stock / Made to Order | Carbon Footprint |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Priora Pencil Edge 200 x 100 x 80 Natural | PV6570250 | 200 x 100 | 200 | 100 | 80 | 3.5 | 1040 | 6.2 | Standard | 18750 | Made To Order | 20 kg CO2 m² |
| Priora Pencil Edge 200 x 100 x 80 Charcoal | PV6570500 | 200 x 100 | 200 | 100 | 80 | 3.5 | 1040 | 6.2 | Standard | 18750 | Made To Stock | 20 kg CO2 m² |
| Priora Pencil Edge 200 x 100 x 80 Buff | PV6570750 | 200 x 100 | 200 | 100 | 80 | 3.5 | 1040 | 6.2 | Standard | 18750 | Made To Order | 20 kg CO2 m² |
| Priora Pencil Edge 200 x 100 x 80 Brindle | PV6571750 | 200 x 100 | 200 | 100 | 80 | 3.5 | 1040 | 6.2 | Standard | 18750 | Made To Stock | 20 kg CO2 m² |
Made to stock: Item is in stock and available for delivery.
Made to order: Item will be manufactured when the order has been placed, lead times vary dependent on product.
